Stock Size Safety Nets
Product overview Stock Size Safety Nets
100mm Mesh Fall Arrest Safety Net with Border Rope - 7.5m x 15m
Article number
19043-100
execution
edged all round with rope
material diameter
5 mm
mesh
square
mesh size
100 mm
With
Border rope
material
high tenacity polypropylene, knotless
Size
7.50 x 15 m
Mesh breaking strength
3.00 kN
Energy absorption
4.6 kJ
Tensile Strength of Edged Rope
30 kN
Total Weight
23,85 kg
weight per m²
275 g/m²
Standards and Rules
BG regulation no. 179, DGUV standard 101-011, EN 1263-1
Certificate
GS verification certificate 18100015, Oeko-Tex® certificate 12.0.02466 (Standard 100)
Net class
A2
Safety net system
S (rope-edged safety net)
Regular Inspection Interval
12 months
Number of test meshes
3 pcs.
Continuous operating temperature
-40 to +80 °C
Melting point
165 °C
Bending strength & abrasion resistance
good
Weather resistance
good
UV-Resistance
300 kly
Tensile strength after two years of climatic influences
90%
Customs tariff number
5608 19 30
Unit price
£ 333.14
100mm Mesh Fall Arrest Safety Net with Border Rope - 5m x 10m
Article number
19040-100
execution
with border rope
material diameter
5 mm
mesh
square
mesh size
100 mm
With
Border rope
material
high tenacity polypropylene, knotless
Size
5 x 10 m
Mesh breaking strength
3000 N
Energy absorption
4,6 kJ
Tensile Strength of Edged Rope
30 kN
Total Weight
11.65 kg
weight per m²
275 g/m²
Standards and Rules
BG regulation no. 179, DGUV standard 101-011, EN 1263-1
Certificate
GS verification certificate 18100015, Oeko-Tex® certificate 12.0.02466 (Standard 100)
Net class
A2
Safety net system
S (rope-edged safety net)
Regular Inspection Interval
12 months
Number of test meshes
3 pcs.
Continuous operating temperature
-40 to +80 °C
Melting point
165 °C
Bending strength & abrasion resistance
good
Weather resistance
good
UV-Resistance
300 kly
Tensile strength after two years of climatic influences
90%
Customs tariff number
5608 19 30
Unit price
£ 148.06
100mm Mesh Fall Arrest Safety Net with Border Rope - 6m x 10m
Article number
19041-100
execution
edged all round with rope
material diameter
5 mm
mesh
square
mesh size
100 mm
With
Border rope
material
high tenacity polypropylene, knotless
Size
6 x 10 m
Mesh breaking strength
3.00 kN
Energy absorption
4.6 kJ
Tensile Strength of Edged Rope
30 kN
Total Weight
13.35 kg
weight per m²
275 g/m²
Standards and Rules
BG regulation no. 179, DGUV standard 101-011, EN 1263-1
Certificate
GS verification certificate 18100015, Oeko-Tex® certificate 12.0.02466 (Standard 100)
Net class
A2
Safety net system
S (rope-edged safety net)
Regular Inspection Interval
12 months
Number of test meshes
3 pcs.
Continuous operating temperature
-40 to +80 °C
Melting point
165 °C
Bending strength & abrasion resistance
good
Weather resistance
good
UV-Resistance
300 kly
Tensile strength after two years of climatic influences
90%
Customs tariff number
5608 19 30
Unit price
£ 177.68
100mm Mesh Fall Arrest Safety Net with Border Rope - 10m x 10m
Article number
19042-100
execution
edged all round with rope
material diameter
5 mm
mesh
square
mesh size
100 mm
With
Border rope
material
high tenacity polypropylene, knotless
Size
10 x 10 m
Mesh breaking strength
3.00 kN
Energy absorption
4.6 kJ
Tensile Strength of Edged Rope
30 kN
Total Weight
21,20 kg
weight per m²
275 g/m²
Standards and Rules
BGR 179, DGUV Regel 101-011, DIN EN 1263-1
Certificate
GS verification certificate 18100015, Oeko-Tex® certificate 12.0.02466 (Standard 100)
Net class
A2
Safety net system
S (rope-edged safety net)
Regular Inspection Interval
12 months
Number of test meshes
3 pcs.
Continuous operating temperature
-40 to +80 °C
Melting point
165 °C
Bending strength & abrasion resistance
good
Weather resistance
good
UV-Resistance
300 kly
Tensile strength after two years of climatic influences
90%
Customs tariff number
5608 19 30
Unit price
£ 296.13
100mm Mesh Fall Arrest Safety Net with Border Rope & Ties - 6m x 10m
Article number
21031-100
execution
edged all round with rope and suspension ropes
material diameter
5 mm
mesh
square
mesh size
100 mm
With
Border and ties
material
high tenacity polypropylene, knotless
Size
6 x 10 m
Mesh breaking strength
3200 N
Energy absorption
4,8 kJ
Tensile Strength of Edged Rope
30 kN
Tensile Strength of Suspension Rops
30 kN
Total Weight
16.75 kg
weight per m²
275 g/m²
Standards and Rules
BG regulation no. 179, DGUV standard 101-011, DGUV information 201-010, EN 1263-1
Certificate
GS verification certificate 18100013, Oeko-Tex® certificate 12.0.02466 (Standard 100)
Net class
A2
Safety net system
S (rope-edged safety net)
Regular Inspection Interval
12 months
Number of test meshes
3 pcs.
Continuous operating temperature
-40 to +80 °C
Melting point
165 °C
Bending strength & abrasion resistance
good
Weather resistance
good
UV-Resistance
300 kly
Tensile strength after two years of climatic influences
90%
Customs tariff number
5608 19 30
Unit price
£ 319.82
100mm Mesh Fall Arrest Safety Net with Border Rope and Ties- 5m x 10m
Article number
21030-100
execution
edged all round with rope and suspension ropes
material diameter
5 mm
mesh
square
mesh size
100 mm
With
Border and ties
material
high tenacity polypropylene, knotless
Size
5 x 10 m
Mesh breaking strength
3.20 kN
Energy absorption
4.8 kJ
Tensile Strength of Edged Rope
30 kN
Tensile Strength of Suspension Rops
30 kN
Total Weight
14.60 kg
weight per m²
275 g/m²
Standards and Rules
BG regulation no. 179, DGUV standard 101-011, EN 1263-1
Certificate
GS verification certificate 18100013, Oeko-Tex® certificate 12.0.02466 (Standard 100)
Net class
A2
Safety net system
S (rope-edged safety net)
Regular Inspection Interval
12 months
Number of test meshes
3 pcs.
Continuous operating temperature
-40 to +80 °C
Melting point
165 °C
Bending strength & abrasion resistance
good
Weather resistance
good
UV-Resistance
300 kly
Tensile strength after two years of climatic influences
90%
Customs tariff number
5608 19 30
Unit price
£ 266.51
